The EZ Digital GP-1305DU DC Power Supply with Dual Output supplies output voltages of 0-30V and 0-50V with an auto tracking feature.
Features
| Chracteristics: | EZ Digital GP-1305DU DC Power Supply with Dual Output |
| 0-30V & 0-50V variable outputs | |
| 0-3A, 0-5A, 3A (fixed) output currents | |
| Low noise and ripple | |
| Constant current and constant voltage | |
| 3 digit green LED screen | |
| Auto tracking feature | |
| Parallel and auto series operation | |
| Over load and over voltage protection | |
| On/Off control | |
| No load current limit control function | |
| Optional remote control operation |
Specifications
| Specifications | EZ Digital GP-1305DU Dual Output DC Power Supply | |
| Output voltage & current | Independant | 0~±30V/0~5A |
| Serial | 0~60V/0~5A | |
| Parallel | 0~30V/0~10A | |
| Fixed output voltage (TP models only) | -----------N/A----------- | |
| Ripple / noise | ≤1mVrms | |
| Regulation | Line | ≤0.01%+2mV |
| Load | ≤0.01%+3mV | |
| 5V fixed output (TP models only) | -----------N/A----------- | |
| -----------N/A----------- | ||
| -----------N/A----------- | ||
| -----------N/A----------- | ||
| -----------N/A----------- | ||
| Display Accuracy (V/A) | ±(1%of rdg. ±1 digit) | |
| Tracking Operation | Tracking error : less than ±0.5%+8mV | |
| Series regulation : less than 300mV | ||
| Protection | O.V.P : when the output voltage is exceeded by approx. 110% of the maximum voltage (output voltage cut-off) | |
| Output on/off control : output is produced only when power s/w and output s/w on(to prevent unexpected output) | ||
| Overload protection(C.C. mode) : output voltage comes down when the output current reaches to the set value | ||
| Insulation | Between chassis and output terminal : 20MΩ or above (DC 500V) | |
| Between chassis and AC cord : 50MΩ or above (DC 500V) | ||
| Ambient Temperature | 0°C ~ +40°C | |
| Power Source | AC90-132V, AC198-264V, 50/60Hz | |
| Dimensions | 9.25" x 5.35" x 14.57" (235 x 136 x 370mm) | |
| Weight (Approx) | 31lbs (14kg) | |
| Accessories | Short circuit bar x2, fusex1, operator's manual, AC power cord | |
